4MP 1/3" OV4689 + FH8538M AHD TVI CVI Analog 4 in 1 HD Camera BOARD FOR CCTV Camera

Empty

Total: $0.00

Hupuu Electronics

SKU:

A4CB-8538V689-C

Category: AHD CVI TVI Analog 4 in 1

Video Coding Format: AHD Analog (CVBS) CVI TVI

$12.47

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $10.76 - $12.47

Imaging Sensor: OV4689

Effective Pixels: 4MP

Description

4MP 1/3" OV4689 + FH8538M AHD TVI CVI CVBS 4 in 1 Coaxial Camera BOARD FOR CCTV Camera

WDR, 2D NR，Support AHD CVI TVI CVBS four in one

Support OSD + UTC matching

HD, Exquisite images, Strong sense of hierarchy

Transient suppression diode anti-static, Lightning protection design

Low power Schottky diode to prevent reverse power supply

SKU:	A4CB-8538M4689-C
Chipset:	1/3" 4689 + FH8538M
Effective Pixel:	4MP 2688x1520
System:	PAL(default)/NTSC
Dynamic range:	64dB
Synchronously:	Internal
Operation environment:	-20°C - 60°C RH<95%
Video output:	10bit RAW RGB(AHD/CVI/TVI) + CVBS 1.0Vp-p 75Ω
Power Supply:	12V±10%
Working Current:	65mA
Size:	38x38mm/32x32mm
