A4CB-8556S415 8MP 1/2.8" Sony IMX415 + FH8556 4K AHD TVI CVI Analog 4 in 1 hybird Security CCTV CMOS HD Camera Module Board

• Use 8MP CMOS，captured images.

• high-definition 4K output, clear image.

• Lux: 0.01Lux@(F1.2,AGC ON)，0LUX with IR

• Support IR-CUT，CDS external control , D/N mode.

• Support OSD and suitable for user-defined settings;

• Suport DWDR;


• Adaptive Digital Noise Reduction 2D-DNR 3D-DNR;

• Support UTC

OSD Switch:  Default signal is AHD,switch from OSD Menu.

UP:AHD  DOWN:CVI  LEFT:TVI  RIGHT:CVBS（Press about 5 second).

(Can be switch without AF function)

OSD Control for AF Setting

UP/DOWN: Zoom

Left/Right: Focus

Video Format：

PAL/NTSC can be changed from OSD Menu.
