Sensor Optical Format: 1/1.8"

Imaging Sensor: IMX678

Effective Pixels: 8MP

Hole Distance: 22mm

Bottom Group

Description

HK678D 1/1.8" Starvis2 SONY IMX678 8MP 30fps H.265 IP Starlight Security CCTV HD Camera Module board

Feature:

1/1.8" 8MP Sony Starvis2 IMX678 CMOS sensor
HTML5 plugin free web page access video preview for Chrome IE Edge Firefox Safari Browsers
Standard 38*38 dual board structure
Support H.265+, H.265, H.264 encoding
Support image flip, support backlight compensation, glare suppression, 3D digital noise reduction, fog transmission, support digital wide dynamic
support IR/full color/Dual light mode, support PWM dimming
Support standard ONVIF, GB28181
Support motorized zoom (optional), auto iris (optional)
Provide SDK development kit, support secondary development
Intelligent functions: motion detection

SOC	Hi3519DV500,Cortex A55@1000MHz
Sensor	1/1.8" Progressive Scan Starvis 2 CMOS IMX678
Min illumination	Color: 0.001Lux@F1.0(AGC ON), Black & White: 0Lux(IR ON)
WDR	100 dB

Main Stream Resolution	30 fps@（3840x2160, 2880x1620, 2560x1440,1920×1080）
Sub Stream Resolution	30 fps@（704×576,640×480）
Coding	H.265+/H.265/H.264
Bitrate	512 Kbps~32 Mbps
H.264 coding	Baseline Profile/Main Profile/High Profile
H.265 coding	Main Profile
Bitrate	CBR,VBR
Character Overlay	Support
Image watermark overlay	Support
Image Enhance	Backlight compensation, glare suppression, 3D digital noise reduction, fog transmission
Image settings	Rotation, saturation, brightness, contrast, sharpness, AGC, white balance, day/night conversion support

Audio port	1ch input, support mic / line in; 1ch output support earphone or amplifier
Audio sampling bitrate	8 kHz
Audio coding format	G.711u law / G.711a law / G.726 / AAC-LC(32K)

Preview channels	12ch MAX
Protocol	HTTP, HTTPS, TCP/IP, UDP, RTP, FTP, RTCP, RTSP, NTP, DHCP, DNS, DDNS, SNMP, SSL/TLS, WebSocket, UPNP, PPPOE Etc., Support ONVIF standard protocol
Browser	Preview with plugin: IE10,IE11 Preview with local service: Edge,Chrome,Firefox etc.

Network	1 RJ45 Ethernet port, 10M/100M adaptive
Audio	1ch input, support for Mic or line in; 1ch output, support for connecting headphones or amplifiers
LED light	Support photosensitive detection input, support PWM dimming
USB	1 USB2.0 (5V Power), Support 4G/WiFi/Storage/UVC
Reset	Support

Size	38x38x18mm,38mm dual board structure
Weight	34 g
Working temperature	-20°C ~ +60°C
Power consumption	DC12V Power input, 4W (Max)
