1/2" 2MP CMOS sensor IMX385, 38*38mm double board.
22mm
HP678D-AZ3 1/1.8" Starvis2 SONY IMX678 8MP 30fps 3.6-11mm motorized Zoom H.265 IP Starlight Security CCTV HD Camera Module board
1/1.8" 4MP Sony lMX347 CMOS sensor
Standard 38*38 single board structure
Support H.265+, H.265, H.264 encoding
Support image flip, support backlight compensation, glare suppression, 3D digital noise reduction, fog transmission, support digital wide dynamic
support IR/full color mode, support PWM dimming
Support CVBS analog video output (optional)
Support standard ONVIF
Height available: 13.7mm
Hole Distance: 22mm
Filter: 650nm IR-CUT filter
Need Screw like below to mound this holder on camera board and fix lens. (not include by default)
Model: PM2.0x4 or PM2.0x5
L: 4mm / 5mm
P: 0.4mm
d: 2mm
DK: 3.5mm
K: 1.3mm
Package List:
1pcs M12 lens holder without lens
Height available: 12mm
Hole Distance: 20mm
Filter: 650nm IR-CUT filter
Need Screw like below to mound this holder on camera board and fix lens. (not include by default)
Model: PM2.0x4 or PM2.0x5
L: 4mm / 5mm
P: 0.4mm
d: 2mm
DK: 3.5mm
K: 1.3mm
Package List:
1pcs M12 lens holder
Height available: 7mm
Hole Distance: 22mm
Need Screw like below to mound this holder on camera board and fix lens.
Model: PM2.0x4
L: 4mm
P: 0.4mm
d: 2mm
DK: 3.5mm
K: 1.3mm
Package List:
1pcs M12 lens holder
Height available: 14mm
Hole Distance: 22mm
Package List:
1pcs CS lens holder
MODEL | HS781FS327-D30 |
DSP | Eyenix EN781F |
Image Sensor | 1/2.8" Sony IMX327 sensor |
Effective Pixels | 1920(H) × 1080(V) |
Scanning System | Progressive |
Resolution | Digital: 1080p(60fps/50fps 30fps/25fps) |
Min.lllumination | Color: 0.001 lux ,BW: 0.0005 lux , Color:DSS:0.00017 lux , |
Outer Dimensions: 17.7 * 16.5 * 15.2mm
Inner Dimensions: 15.5 * 14.3 * 8.3mm
Lens Mount: D14
Hole Distance: 22mm
Package List:
1pcs M12 lens holder
Feature Support:
Audio in/out, Alarm in, reset, RS485, CVBS, USB
Video coding: H.265/H.264, support dual stream,
Max resolution: 1920*1080,
Color: 0.001Lux@F1.2
WDR: >120db
support back-light compensation during the day, suit for back-light camera, such window and door.
Model | IPCB-3516D327-D29 (-AI -AZ -ET9) | |
Hardware |
