1/2.7" OV2710 AR0230 2MP 1080P Dual Sensor 30fps USB2.0 USB UVC Camera board YUY2 MJPEG

Empty

Total: $0.00

Hupuu Electronics

SKU:

UCB-2D271230

Category: Camera Board USB UVC Camera Module

$85.00

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $63.00 - $85.00

Description

2 Megapixel 1080P HD High Frame Rate USB Camera 30fps

Using 1/2.7 OV2710 CMOS Sensor for B&W.
Using 1/2.7" AR0230 CMOS sensor for color.
Resolutions: 1920x1080, 1280x720, 640x480, 320x240;
Mainly used for Android advertising, video conferencing, high-definition monitoring, refrigerators and other fields.

Sensor for B&W	OV2710
MAX effective pixels	1920 x 1080
Sensor Size	1/2.7 inch
Pixel Size	3.0μm x 3.0μm
Image area	3888μm x 2430μm
Output parameters	video format	Max Rosolution	Frame rate
	YUY2/MJPEG	1080P	30fps
input clock frequency	/
focusing	Manual (for Fixed Focal length Lens)
dynamic range	69dB
Interface type	USB2.0
Adjustable parameter	Contrast, Saturation, Sharpness, White Balance, Exposure
audio	Not support
power	USB BUS POWER
Voltage	DC 5V
Electric current	200mA
Main chip	DSP/SENSOR/FLASH
PCBA Size	Customizable
Storage temperature	-20°C to 70°C
working temperature	0°C to 60°C
USB Wire rod	Customized
System support	WinXP/Vista/Win7/Win8/Win10 Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later
Lens	Image Format	1/2.7"
	TTL	15.6mm
	Construction	2G2P+IR
	FOV	95°
	Thread Size	M12*P0.5mm
	Focus	Fixed

Sensor for Color	AR0230
MAX effective pixels	1928 x 1088
Sensor Size	1/2.7 inch
Pixel Size	3.0μm x 3.0μm
Output parameters	video format	Max Rosolution	Frame rate
	YUY2/MJPEG	1080P	30fps
input clock frequency	/
focusing	Manual (for Fixed Focal length Lens)
max S/N ratio	39dB
dynamic range	105dB
Interface type	USB2.0
Adjustable parameter	Contrast, Saturation, Sharpness, White Balance, Exposure
audio	Not support
power	USB BUS POWER
Voltage	DC 5V
Electric current	200mA
Main chip	DSP/SENSOR/FLASH
PCBA Size	Customizable
Storage temperature	-20°C to 70°C
working temperature	0°C to 60°C
USB Wire rod	Customized
System support	WinXP/Vista/Win7/Win8/Win10 Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later
Lens	Image Format	1/2.7"
	TTL	15.6mm
	Construction	2G2P+IR
	FOV Diagnal	95°
	Thread Size	M12*P0.5mm
	Focus	Fixed
