LF5-M16-5MP-F0.9 Night Vision F0.9 5mm 5MP 1/1.8" M16 Mount starlight night vision Security CCTV Camera Lens

Empty

Total: $0.00

Checkout

Hupuu Electronics

LF2.9-M12-5MP-F1.8 2.9mm focal length 1/2.7" F1.8 M12 HFOV 120 degree lens for IMX307 IMX327 IMX290 IMX291 OS05A10

LF2.19-M12-5MP-F2.45 2.19mm IP69K waterproof focal length 1/2.8" IMX291 F2.45 M12 lens for IMX307 IMX327 IMX290 IMX291

LF5-M16-5MP-F0.9 Night Vision F0.9 5mm 5MP 1/1.8" M16 Mount starlight night vision Security CCTV Camera Lens

LF5-M16-5MP-F0.9 Night Vision F0.9 5mm 5MP 1/1.8" M16 Mount starlight night vision Security CCTV Camera Lens

SKU:

LF5-M16-5MP-F0.9

Category: Lens M16 Lens F1.0 M16 Starlight Lens

$12.80

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $10.80 - $12.80

Sensor Optical Format: 1/1.8"

Effective Pixels: 4MP

Aperture: F1.0

Focal Length: 5mm

Bottom Group

Description

Number	item		specifications
2-1	Aperture (F/NO)		0.9 + / - 5%
2-2	Focal length (EFL)		5 mm + / - 5%
2-3	Total optical length (TTL)		48.6 mm + / - 0.2 mm
2-4	Optical afterfocus (BFL)		6.48 mm + / - 0.2 mm
2-5	Mechanical afterfocus (FFL)		5.35 mm + / - 0.2 mm
2-6	Image face size (Image circle)		8.9 mm (MAX)
2-7	Field of View (FOV)	Sensor	D (diagonal)	H (Level)
		1/1.8	118 °	88 °
2-8	Optical Distortion		-42%
2-9	Relative illumination		40%
2-10	CRA		5.25 Degree
2-11	Spectral Transmission		440~680nm T>80%
2-12	MOD		0.5m
2-13	Lens structure		10G
2-14	Mount		M16 *P0.5


FAQ

1. How to choose the FOV?

By default the FOV in specifications H:V is 4:3, if you use 16:9 sensor the FOV(H) will be wider, and FOV(V) will be smaller.

2. There are 1/1.8" 1/2" 1/2.5" 1/2.7" 1/3", Which one meets my needs?

The image format depends on the sensor format. The image format of lens should be equal or larger than the sensor format, otherwise there will be black area or corner.
