ICR2216G-M16 CCTV Camera M16 mount IR-CUT Filter For IP Camera Board 1/1.8" IMX178 IMX185 M16

SKU:

ICR2216G-M16

Category: IR-CUT Dual Filters switch

$5.40

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $3.20 - $5.40

Hole Distance: 22mm

Mount: CS

Accessories: Lens Holder

Bottom Group

Description

Packing list:

1 x CCTV Camera IR-CUT Filter 8MP (22mm）

1 x M16 Lens Holder (38mm * 38mm) (Optional)

-----------------------------------------------------------------------------------------

1/2" And 1 / 1.8" CMOS SONY IMX178 IMX385 Sensor Dedicated

1/1.8" Large size infrared filter

IR-CUT Removable module parameter
Filter can use effective area	diagonal 10.11mm
Operating environment	temperature -20~60°C humidity 10-85%
Rated Current	35mA
drive voltage	3.3-12V
Pulse time	100-500ms
Storage environment	temperature -20~60°C humidity 10-85%
