6K HD 12MP IMX577 USB Camera MJPEG YUV Module H.264 Industrial 30 fps USB Type-c 3.0 UVC Driver Free Manual Focus

Empty

Total: $0.00

Hupuu Electronics

SKU:

UCB-12M577MF

Category: USB UVC Camera Module

$105.00

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $99.00 - $105.00

Sensor Optical Format: 1/2.3"

Imaging Sensor: IMX585

Effective Pixels: 12MP

Description

Product model	UCB-12M577AF
Sensitive film	1/2.3”
Most significant pixel	H4000×V3000
Sensitivity	1000mv/Lux-sec
Imagearea	6.100mm x 4.524mm
Output image format	MPEG/YUY2 (YUYV) /H.264
Supported resolution and dun rate	Resolution MJPG (fps)	YUY2 (fps)	H.264 (fps)
	4000 x 300020	10
	303840 x 2160	5
	2592x194430	25
	2688 x 151230	5
	2048x153630	30
	1600 x 120030	30
	301920 x 1080	30	30
	1280 x 96030	30
	1280 x 72030	30	30
	960 x 54030	30
	800 x 60030	30
	640 x 48030	30	30
	30640 x 360	30
Center Resolution	1000LW/PH (Center)
Signal-to-noise ratio	26dB
sensitivity	0.65 v/lux - SEC @ 550 nm
Minimum illumination	0.2 lux
Shutter type	Electronic rolling shutter/ Frame exposure
Interface type	USB3.0 High Speed /USB 2.0
Automatic light burst control AEC	support
Automatic white balance AEB	support
Automatic gain control AGC	support
Adjustable parameter	Brightness contrast color saturation tonal clarity Youma Bai balance backlight contrast exposure
Lens specification	Size: 1/2.3, FOV: 100Degree
	Relative lllumination (Sensor): 70%
	Infrared filter: 650±10nm
Power Supply and ports	1.255PIN USB2.0 port /Type-cUSB3.0 port
voltage	DC 5V
Electric current	200mA
Storage temperature	-20° Cto70°C
Operating temperature	5.099.0
USB cable	1M (2M/3M/5M optional)
Systems support	WinXP/Vista/Windows 7 / doing/Win10 Linux with UVC (above linux - 2.6.2) MAC - OSX10.4.8 or later / Android4.0 or above with UVC
