720P Analog CVBS Endoscopy Video Processor for Endoscope Camera System Medical Imaging Parts

Empty

Total: $0.00

Hupuu Electronics

SKU:

SP-CMH

Category: Medical Endoscope Camera

$199.00

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $179.00 - $199.00

Sensor Optical Format: 1/3"

Imaging Sensor: IMX225

Effective Pixels: 2MP

Description

720P Analog CVBS Endoscopy Video Processor for Endoscope Camera System Medical Imaging

CVBS endoscope camera system is fully functional endoscopy solutions of specifically designed for industrial medical.

CVBS input, VGA/CVBS output, there are control menu and shortcut key function. Widely used in medical industry.

● 1/3" SONY CMOS IMX225, 720p resolution;
● 1-20 steps brightness adjustment, 1-10 steps sharpness, 1-10x D-zoom;
● FRESS, AWB, Multi- languages;


Video processor
Input	CVBS (1000TVL)
Output	VGA CVBS
OSD menu	UP DOWN LEFT RIGHT SET/Confirm
Output resolution	720P
Backlight	OFF/BLC/HLC/WDR
AWB	AUTO/MANUAL
FREEZE	Support
D-Zoom	1-10x
Temperature	-30°C ~ 70°C
Language	Chinese English etc
Power Supply	AC110-240V

Optional Camera Handler 1 (NOT INCLUDE by default)
Image Sensor	1/3" SONY CMOS IMX225
Effective Pixels	1312(H) x 993(V) Approx. 1.30M pixels
Cell size	3.75um*3.75um
Resolution	CVBS：720P@50fps / 60fps
FREEZE	Picture freeze
AWB	automatic / manual
D-ZOOM	image zoom 1-10X
Color	RED/GREEN/YELLOW/BLUE
Brightness	1-20 steps
Sharpness	1-10 steps
Language	Chinese, English etc
Working temperature	-10°C to 75°C
Power（Max.） supply	DC12V ±10%<1.7W
Working Current	140mA±10mA
Size	-
Weight	300g

Support shortkey to adjust AWB and freeze.


AWB：Before use，point the lens at the white paper, press the white balance button and wait for the white balance to adjust.

Supports Color Adjustment.

Remarks:

In different lens modes, optical lenses should be matched. Some shots match as below:

Package:

optional Endoscope camera handler (without endoscope lens, without lens coupler)

1x 720P Endoscope Analog Video Processor
