5MP OV5640 MIPI Auto Focus Camera Module Board

5MP OV5640 MIPI Auto Focus Camera Module Board

5MP OV5640 MIPI Auto Focus Camera Module Board

5MP OV5640 MIPI Auto Focus Camera Module Board

SKU:

MIPI-OV5640

Category: MIPI Camera Board

$10.60

Need parts to be Assembled for free? Please contact us, or leave message when checkout.

For batch orders please contact us.

Price: $9.20 - $10.60

Effective Pixels: 5MP

Bottom Group

Description

5MP OV5640 MIPII Camera Module Board Auto focus

Item	parameter
Max pixel	5MP 2592*1944
Sensor	OV5640
Color	8bit * 3 True Color
Focus	>0.3m
Focal Length	4.2mm
Optical Structure	4G+IR-CUT650
FOV	62 degree
Aperture	F2.4
Distortion	< 1%
Frame Rate	30fps@24MHz, VGA
Output	YCbCr4:2:2, RGB565, RAW RGB
Connector	15pin
Operating Voltage	1.7 - 3.0V
Power	90mW / 30uW
Operating Temperature	-20°C - 70°C
